- Socket
- LGA1700
- DIMM
- 4 slots
- Slots
- 3x x16
Why this part
- Solid 14700K/14900K board
- 18-phase VRM, adequate for 253W
- Four M.2
Bench tested under load for 48 hours. Visible cosmetic wear, no functional impact.
Covered by a 6 month warranty from us directly.
Specification
Platform
- Socket
- LGA1700
- Chipset
- Intel Z790
- Form factor
- ATX
- VRM phases
- 18
- EPS headers
- 2 x 8-pin
Memory
- Generation
- DDR5
- Slots
- 4
- Accepted
- UDIMM
- Max speed
- 7200 MT/s
- Max capacity
- 192 GB
- ECC
- No
Expansion
- Slot 1
- Gen 5.0 x16 mechanical, x16 wired
- Slot 2
- Gen 4.0 x16 mechanical, x4 wired, narrower than it looks
- Slot 3
- Gen 3.0 x16 mechanical, x4 wired, narrower than it looks
Storage & network
- M.2 slots
- 4 (up to Gen 5.0)
- SATA ports
- 6
- U.2 ports
- 0
- Onboard network
- 1 x 2.5 GbE
- Out-of-band management
- None
- BIOS flashback
- Yes
Same part, other grades and partners
3 other SKUs built on the same processor. The price difference comes from condition grade, board partner and cooler design, not from the chip itself.
